Description
xTired of hearing your items knocking around in the back of your trailer? Keep them steady and separate with Kinedyne's 2" by 20' Logistic Ratchet Strap with Series F 1" Notched Hole Track Key Fittings with a working load limit of 670 Lbs. / 305 Kgs.
2-Inch x 20-Foot Series F Key Fitting Logistic Ratchet Strap
If you're looking for a reliable way to tie down your cargo, then you've found it with Kinedyne's strong and durable 2-Inch x 20-Foot Logistic Ratchet Strap with Series F 1-Inch Notched Hole Track Key Fittings. All you need to do is hook one end into your Series F Track, wrap the webbing around the cargo, and then hook the other end to either the same Series F Track or to another anchor point.
The Kinedyne C1823 Series F 1" Notched Hole Track Key Fittings are designed to provide you with a solidly reliable hold in your Series F Track. They can be smoothly inserted into the Track in a matter of seconds, and then they can be removed just as quickly, making for a quick and easy tie down job.
Working together, the Kinedyne blue 4900E webbing and the Kinedyne 811 Standard Handle Ratchet provide you with a reliable tensioning job. The heat-treated carbon steel Ratchet pumps back and forth to tighten down our polyester webbing to create a viselike grip over the cargo, keeping it steady and in place.
All Kinedyne Logistic Straps are tagged and stenciled with the manufacturer's name and logo and the working load limit to comply with CHP, WSTDA, North American Cargo Securement, and CVSA standards and DOT regulations. Remember that your cargo control system is only as strong as its weakest link.
2" by 20' Key Fitting Logistic Ratchet Strap – 642015 Quick Specs:
- Working Load Limit: 670 Lbs. / 305 Kgs.
- Series Type: Series F Canada
- Width: 2 Inches
- Length: 20 Feet
- Weight: 2.49 Lbs. / 1.13 Kgs.
- Webbing: Kinedyne Blue 4900E Webbing
- Fixed End Length: 4 Feet
- Type of Tension Device: Kinedyne 811 Standard Handle Ratchet
- End Fitting: Kinedyne C1823 Series F 1 Inch Notched Hole Track Key Fitting
Specifications
xKinedyne 2" by 20' Key Fitting Logistic Ratchet Strap
Tired of hearing your items knocking around in the back of your trailer? Keep them steady and separate with Kinedyne's 2" by 20' Logistic Ratchet Strap with Series F 1" Notched Hole Track Key Fittings with a working load limit of 670 Lbs. / 305 Kgs.
Technical Specifications
- Working Load Limit: 670 Lbs. / 305 Kgs.
- Series Type: Series F Canada
- Width: 2 Inches
- Length: 20 Feet
- Weight: 2.49 Lbs. / 1.13 Kgs.
- Webbing: Kinedyne Blue 4900E Webbing
- Fixed End Length: 4 Feet
- Type of Tension Device: Kinedyne 811 Standard Handle Ratchet
- End Fitting: Kinedyne C1823 Series F 1 Inch Notched Hole Track Key Fitting
Common Applications
- Securing palletized or loose cargo in trailers and vans
- Warehouse load restraint during staging and internal transport
- Distribution center order consolidation and transport
- Industrial facility cargo control and protection
- Maintenance and facility moves where removable Series F track anchoring is used
Safety and Stability
The strap system uses Kinedyne 4900E webbing and a heat-treated carbon steel 811 standard handle ratchet to provide consistent tensioning and secure restraint. All logistic straps are tagged and stenciled with manufacturer and WLL information to comply with CHP, WSTDA, North American Cargo Securement, CVSA standards and DOT regulations. Ensure inspections and use follow applicable cargo securement guidelines.
Key Benefits
- Capacity: 670 lb working load limit for light to medium cargo restraint
- Durability: polyester webbing and heat-treated ratchet for repeated use
- Mobility: Series F key fittings insert and remove quickly for fast load changes
- Efficiency: 20' length and 4' fixed end allow flexible anchoring configurations
- Compliance: tagged and stenciled to meet relevant regulations and standards
Frequently Asked Questions
Q: What track is required for the key fitting?
A: The end fitting is a Kinedyne C1823 Series F 1" notched hole track key fitting and requires Series F track.
Q: What is the working load limit and recommended use?
A: The working load limit is 670 lbs (305 kg); use for light to medium cargo restraint where rated capacity is appropriate.
Ordering and Shipping
Contact Material Handling Canada to purchase or request a quote for bulk orders, custom kits, or shipping options. Visit materialhandlingcanada.com or contact our sales team to order, confirm availability, and arrange delivery to your facility.
