MELCHER MANUFACTURING 1030 MEDIUM DUTY SINGLE RAMP

MELCHER MANUFACTURING 1030 MEDIUM DUTY SINGLE RAMP

Vendor: Melcher Manufacturing
SKU: 1030
Availability: Many In Stock
Product type: Material Handling
$2,139.88
$2,139.88
$2,139.88
Save $0.00
Size: 10 ft x 30 in
Subtotal: $2,139.88
MELCHER MANUFACTURING 1030 MEDIUM DUTY SINGLE RAMP

MELCHER MANUFACTURING 1030 MEDIUM DUTY SINGLE RAMP

$2,139.88
MELCHER MANUFACTURING 1030 MEDIUM DUTY SINGLE RAMP

MELCHER MANUFACTURING 1030 MEDIUM DUTY SINGLE RAMP

$2,139.88
Size: 10 ft x 30 in
Description
Description
x
Model Length (FT) Width (IN)* Capacity (LBS) Weight (LBS) Working Height Range (IN)
1030 10 30 3000 103 20-30

*Subtract 2" for usable width.
Maximum load pressure of 200 pounds per square inch (psi).
Ramp must be pinned while in use.
Not to be used with pallet jacks or forklifts. Not sold as dock boards.

Features:
. 1" safety curb height.
. Non-skid walking surface provides safe, secure footing in wet and dry weather.
. Securing pin with in-ramp storage.
. Optional securing chains can be added for an additional cost.
. Optional easy lift straps.
. Easy roll transitions on/off ramp.

Specifications
Specifications
x

MELCHER MANUFACTURING 1030 MEDIUM DUTY SINGLE RAMP

The MELCHER MANUFACTURING 1030 MEDIUM DUTY SINGLE RAMP by Melcher Manufacturing is a best-selling, top-of-the-line single ramp engineered for medium-duty loading tasks. Designed for safe pedestrian and hand-cart transfer, it features a non-skid walking surface, 1" safety curbs, and in-ramp securing pin storage. Notes: subtract 2" for usable width; maximum load pressure 200 psi; ramp must be pinned while in use; not for use with pallet jacks or forklifts and not sold as a dock board.

Technical Specifications

  • Model: 1030
  • Length (ft): 10
  • Width (in)*: 30
  • Capacity (lbs): 3000
  • Weight (lbs): 103
  • Working height range (in): 20-30

Common Applications

  • Warehouse loading and unloading
  • Distribution center staging
  • Industrial facility access and transfers
  • Maintenance bays and service platforms
  • Temporary loading platforms for shipments

Safety and Stability

The ramp includes a 1" safety curb and non-skid walking surface to reduce slip risk. Secure with the supplied pin (in-ramp storage) and consider optional securing chains. Observe the 200 psi maximum load pressure and do not use with pallet jacks or forklifts.

Key Benefits

  • High capacity: 3,000 lb rated for medium-duty loads
  • Durable construction suitable for industrial environments
  • Portable: manageable 103 lb weight for positioning and storage
  • Efficient transitions with easy roll features for hand carts and pedestrian loads
  • Enhanced safety via non-skid surface and integrated safety curbs

Frequently Asked Questions

Can this ramp be used with pallet jacks or forklifts?

No. The manufacturer specifies the ramp is not to be used with pallet jacks or forklifts.

How is the ramp secured during use?

The ramp must be pinned while in use; a securing pin is stored in-ramp and optional securing chains are available for additional stability.

Ordering and Shipping

To purchase or request a quote, contact Material Handling Canada. For product availability, pricing, and shipping options visit materialhandlingcanada.com or contact our sales team through the site.
