Description
x| Length (FT) | Connected Width (IN)* | Half Width (IN)* | Capacity: Connected/Half (LBS) | Total Weight (LBS) | Working Height Range (IN) | |
| 7530AL | 7 †’ ½ | 30 | 15 | 4000/2000 | 75 | 14-22 |
*Subtract 2" for usable width when connected, 1" when separated.
Maximum load pressure of 200 pounds per square inch (psi).
Ramp must be pinned while in use.
Not to be used with pallet jacks or forklifts. Not sold as dock boards.
Features:
. 1" safety curb height.
. Non-skid walking surface provides safe, secure footing in wet and dry weather.
. Securing pin with in-ramp storage.
. Optional securing chains can be added for an additional cost.
. Easy roll transitions on/off ramp.
Specifications
xMELCHER MANUFACTURING 7530AL HEAVY DUTY 2 IN 1 AUTOLOADER RAMP
The MELCHER MANUFACTURING 7530AL Heavy Duty 2 in 1 Autoloader Ramp is a compact, dual €‘configuration steel ramp designed for safe personnel and hand truck loading operations. Available from Melcher Manufacturing, the unit converts between a full connected width and two half ramps for flexible loading. Non €‘skid walking surface, 1" safety curbs, and in €‘ramp securing pin storage support safe use. The ramp must be pinned while in use, is not intended for pallet jacks or forklifts, and is not sold as a dock board.
Technical Specifications
- Model: 7530AL
- Length: 7 ½ ft
- Connected Width: 30 in (subtract 2 in for usable width when connected)
- Half Width: 15 in (subtract 1 in for usable width when separated)
- Capacity: 4000 lbs (connected) / 2000 lbs (half)
- Total Weight: 75 lbs
- Working Height Range: 14-22 in
- Maximum load pressure: 200 psi
Common Applications
- Warehouse receiving and internal material staging
- Distribution centers for loading/unloading light loads
- Industrial facilities for manual handling and cart transfers
- Facility maintenance and short €‘run transfer operations
Safety and Stability
The ramp features a non €‘skid walking surface and 1" safety curbs to reduce slip and roll €‘off risk. Secure the ramp with the provided pin (stored in €‘ramp) before use. Do not use with pallet jacks or forklifts and comply with the 200 psi maximum load pressure.
Key Benefits
- High capacity: 4000 lbs when connected, 2000 lbs per half for flexible load handling
- Durable construction for repeated industrial use
- Modular 2 €‘in €‘1 design improves mobility and storage
- Non €‘skid surface and safety curbs enhance operator safety
- Lightweight at 75 lbs for easier positioning and roll transitions
Frequently Asked Questions
Can the ramp be used with forklifts?
No. The 7530AL is not to be used with pallet jacks or forklifts and is not sold as a dock board.
How should I secure the ramp during use?
The ramp must be pinned while in use; a securing pin is included with in €‘ramp storage. Optional securing chains are available at additional cost.
